REF · GS-Horse Panel

Horse Stable Panels.

twin bay horse stable panels fitted inside an 8m wide shed retrofit
Two-bay shelter with split mesh and ply walls beside a gravel yard
Guerilla Steel Stables front panel, 4000 × 2400 mm, galvanised 50×50 SHS frame, black ply lower, welded mesh upper, 1500 × 1200 mm swing gate with slam latch.
Build out your shed or extend your stables with individual Australian-made steel panels. Choose front, side and dividing panels with black ply or mesh.
4–6 Week Delivery
20
Reviews
$495.00 – $2,750.00
↳ The range

Browse Stable Panels.

Horse Stable Panels
Every kit & panel is a starting point.
Sizes, gates, panels and #bays all customise.
"If you can think it, we can make it."
— Morgan, Founder

Showing 1–16 of 19 results

↳ At-a-glance
Modular Horse Panels
Individual pre-fabricated steel horse stable panels

Buy individual stable panels for a shed fit-out, an extra bay or changes to your existing layout. Each panel is fabricated in the Guerilla Steel Yatala workshop.

Choose front panels with gates, side panels and dividing walls. Black ply provides a solid barrier, while steel mesh keeps airflow and visibility open. Cattle Rail options are now available and provide secure containment. Combine them to suit the position of each wall and the horses using it. 4m & 5m panel sizes are available to order online, or ask about custom lengths to fit your existing shed posts.

Need something different?
Looking for specific panels or different dimensions? Share details about your available space and what you need for a custom quote.
Get a Custom Quote

Stable Panel Specs

Stable Panels in this range include:
Stall Bays
4×4m
single bay · Inline  · Indoor · Outdoor · Standalone
Sizes
Large
Standard
XLarge
Sizes · Front Orientation
Height
2.4m, airflow-optimised
Taller than most · better ventilation & workflow
Frame
50×50mm
Prefabricated Panels · Cattle Drop Pin & Sleeve Joints · Australian Steel · Galvanised
Gate/Front
Fully Ply Gate
Ply Mesh Gate

1500mm W x 1200mm H Straight Gate with recessed slam latch

1500mm W x 1200mm H Straight Gate with recessed slam latch

Panels
Ply Mesh Combo
Full Ply
2-Rail Cattle Rail
3-Rail Cattle Rail
Prefabricated Panels · Mix Panel Infills · Cattle Drop Pin & Sleeve Joints
Install
DIY (8–14 hrs) or Pro (1 day)
Delivery & Install to South East Qld & Northern NSW
✎
Build it your way
Not sure what Stable OR SHELTER you need?
A 60-second quiz that does the legwork for you. Six questions about your horses and your block, and you'll get a recommendation with a real price, on screen, same page, no email.
Size? # Bays? Price?
↳ In the field

Stable Panel builds working In The Field.

↳ More Info

Building Buying & Owning - Stable Panel

Frequently asked Questions

Our fully welded panels connect using heavy-duty cattle drop pins. The connection points line up and the pins drop into place. The pin sleeve joint make assembly straightforward and allows panels to be reconfigured or additional bays added later.

Standard panel frames measure 4000mm long × 2400mm high × 50mm thick. A standard 4m × 4m stable provides 16m² of internal floor space, with an outside frame measurement of 4100mm × 4100mm.

Each adjoining bay shares a dividing panel and adds 4050mm to the overall length: 4000mm for the additional front panel, plus 50mm for the next end or dividing panel.

ConfigurationOutside frame dimensionsInternal floor area
Single bay4100mm × 4100mm16m²
Two adjoining bays8150mm × 4100mm32m²
Three adjoining bays12,200mm × 4100mm48m²

These are frame dimensions. Roof overhangs extend beyond this footprint and need to be allowed for when planning your site.

The Guerilla Steel range works as one modular system. You can add bays, tack rooms or wash areas anytime without rebuilding the original stable. Front/rear and end/dividing panels are interchangeable across our stables and shelters, making it easy to reconfigure your layout or add more bays later.

If you’re likely to expand, plan the orientation, access and available space from the start.

End and dividing panels use double pin sleeves. Front gate and rear panels use matching single pin sleeves. These line up so the connecting pins can drop into place.

When ordering panels individually, select the correct sleeve configuration for where the panel will sit. If you’re adding to an existing stable, send us a photo of the connection points so we can confirm the match before you order.

No welding or advanced building skills are needed. Each front side and dividing panel arrives fully welded. They connect together with pin and sleeve joints. You’ll need to keep panels square and level, and securely anchor the frame. Have another person help position and hold panels. See the DIY Stable Guide

Have these tools ready:

  • Cordless drill or impact driver
  • Socket and spanner set
  • Spirit level and tape measure
  • Rotary hammer drill if anchoring into concrete
  • Ladder, clamps and appropriate safety gear
